Sealed Type Blind Rivet (Stainless Steel 304/420)
| Mandrel | Material | 420 Stainless steel |
|---|---|---|
| Surface | Natural polish | |
| Body | Material | 304 Stainless steel |
| Surface | Natural polish |
Installation Sequence
Secured,effective installation
- Fully sealed fastener which provides the weather resistance fastener.
- Good hole filling and retained mandrel which can provide the steady vibration resistance riveting.
- Good hole filling and retained mandrel which can provide the steady vibration resistance riveting.
Structure and parameters
Technical Parameters
| Diameter d | Available Sizes | Available Head Types | Body Length L (nom.) | Overall Grip Range | Recommended Drill | Dome Head Max. | Countersunk Head Max. | Mandrel Dia. dm (max.) | Mandrel Reveal P (min.) | Typical Ultimate Strength | |||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| dk | k | dk | k | Tensile | Shear | ||||||||
| 3.2 mm | 3.2×6.0, 8.0, 9.5, 12.0, 14.0 | Dome / Countersunk | 6.0–14.0 mm | 0.5–8.0 mm | 3.3–3.4 mm | 6.7 | 1.3 | 6.7 | 1.3 | 2.05 mm | 27.0 mm | 2200 N | 2000 N |
| 4.0 mm | 4.0×6.0, 8.0, 10.0, 12.0, 14.0, 16.0 | Dome / Countersunk | 6.0–16.0 mm | 0.5–11.0 mm | 4.1–4.2 mm | 8.4 | 1.7 | 8.4 | 1.7 | 2.50 mm | 27.0 mm | 3500 N | 3000 N |
| 4.8 mm | 4.8×8.0, 9.5, 12.0, 14.0, 16.0, 18.0, 20.0 | Dome / Countersunk | 8.0–20.0 mm | 1.0–16.0 mm | 4.9–5.0 mm | 10.1 | 2.0 | 10.1 | 2.0 | 3.05 mm | 27.0 mm | 4400 N | 4000 N |
| 6.4 mm | 6.4×12.0, 16.0, 18.0, 20.0, 25.0 | Dome | 12.0–25.0 mm | 1.5–21.0 mm | 6.5–6.6 mm | 13.4 | 2.7 | N/A | N/A | 3.95 mm | 31.0 mm | 8000 N | 6000 N |
Recommended tool
| Parameter | C864 | C848 |
|---|---|---|
| Capacity All Materials | Φ3.2 — Φ6.4mm | Φ2.4 — Φ4.8mm |
| Pressure Required | 0.5 — 0.7Mpa | 0.5 — 0.7Mpa |
| Pull Force | ≥14.68Kn | ≥9Kn |
| Weight | 1.64kg | 1.45kg |
